Portkeys - BM5IV

5.5” 2000Nits 4K60P HDMI& 3G-SDI Wide Color

Gamut Camera Control Monitor

-  Built-in CINENORM OS, brand new user interface &

user experience.

-  Custom Pages, support custom up to 7 pages, adapt

to different shooting scenes and roles.

-  False color, ARRI false color, user false color, and LOG

false color.

-  User calibration, the user can import two sets of

custom color calibration files, no need to send the

monitor back to the factory for calibrating.

-  Split-screen monitoring, switching PBP, PIP, and H2V

cropping mode freely.

-  User configuration store and loading, settings of the

monitor can be saved to a USB drive and imported

into the same model monitor.

-  Professional monitoring features, like Peaking, Zebra,

Luma Waveform, Luma Histogram, and more.

Box includes:

1x BM5IV Monitor

1x Safety Box

1x  D-Tap to 4-pin aviation connector power cable

1x Micro USB flash stick

1x Customer feedback card

Basic Parameters:

Supported input/output resolution and

frame rate:

Screen Size 5.5"

4K HDMI input/output signal

Dimension 145.4×91.4×39.6mm

4096×2160p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50Hz,59.94Hz,60Hz

Viewing Angle 178°H/178°V

3840×2160p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50Hz,59.94Hz,60Hz

Brightness 2000nits

Resolution 1920x1080

HDMI input/output signal

Contrast Ratio 1000:1

1920×1080p@23.97Hz,24Hz,25Hz,29.97Hz,30Hz,50Hz,59.94Hz,60Hz

Weight 350g

1920×1080psf@23.97Hz,24Hz,25Hz,29.97Hz,30Hz

Color Depth 10bit (8+2FRC)

1920×1080i@50Hz,59.94Hz,60Hz

Material Aluminum alloy

1280×720p@50Hz,59.94Hz,60Hz

Input Voltage 7~24V

720×576p&720×576i@50Hz

Maximum Power 16W

720×480p&720×480i@50Hz,59.94Hz,60Hz

Signal Input 3G SDI, HDMI

Signal Output 3G SDI, HDMI

SDI input/output signal

Audio Output 3.5mm Headphone jack

1920×1080p@50fps,59.94fps,60fps

Power Input 4-Pin aviation connector

1920×1080p@50Hz,59.94Hz,60Hz YUV422

Signal Conversion HDMI/SDI Conversion

1920×1080p@23.98Hz,24Hz,25Hz,29.94Hz,30Hz YUV444/YUV422

Camera Control Interface REMOTE

1920×1080psf@23.98Hz,24Hz,25Hz,29.97Hz,30Hz YUV444/YUV422

TILTA Nucleus Control Interface UART

1920×1080i@50Hz,59.94Hz,60Hz YUV444/YUV422

Supported Battery Model SONY NP-F970/F960/F750/F550

1280×720p@50Hz,59.94Hz,60Hz YUV444/YUV422

USB-A Upgrade firmware / Load LUT

Fan Yes

Operating System CINENORM OS

Version 1 | 01-11-2024
